| SPECIFICATIONS | |
|---|---|
| Wheelbase | 47.2” (120cm) |
| Total Length | 74.8” (190cm) |
| Weight | 34.6 lbs (15.7 kg) |
| Operating Height | 45.3-51.6” (115-131cm) |
| Storing Height (with front wheel) | 45.3” (115 cm) with steering extender |
| Storing Height (no front wheel) | 24.5” (62 cm) without steering extender |
| Crank Length | 5.9” (150mm) |
| Gears/Speeds | 10 |
| Total Gear Range | 382% |
| Avg Gear Step | 16% |
| Gear Ratio Range | .93 – 3.5 |
| Gear Inch Range | 26 – 99 |
| Stride Length | 11.8” (30 cm) |
| Stride Height | 11.8” (30 cm) |
| COMPONENTS | |
| Front and Rear Brakes | Mechanical Disk brakes |
| Grips | Clamp on anti-rotation, with Ergonomic shelf |
| Cranks | Custom forged aluminum |
| Frame | 6061-T6 Aluminum |
| Fork | Air suspension Fork, 100mm travel, variable damping |
| Brake Levers | Two finger levers |
| Propulsion System | Circular Drive |
| Drive Arms | N/A |
| Track System | N/A |
| Chainring | 39-tooth, 130 BCD, 6061 – T6 aluminum |
| Cassette | 10-speed 11-42 tooth range |
| Bottom Bracket | Oversized M48, isis spline, sealed bearings |
| Sprocket | N/A – Uses Cassette |
| Hub | Alloy freewheel hub |
| Steering Column | Adjustable height index locking |
| Steering Extender | Chro-moly steel, antirotation indexing |
| Headset | 1.5” threadless |
| Kickstand | Single leg, forged aluminum kickstand |
| Tires | Kenda Honey Badger, 27.5” x 2.2” 60TPI, 50-psi |
| Handlebar | Alu. MTB Flat bar, 31.8mm dia x 720mm wide |
| Stem | Forged aluminum, 31.8mm dia bar, 80mm x 7 deg |
| Shifter | 10-speed trigger |
| Front Wheel | 27.5” aluminum, tubeless ready, 32-spoke |
| Rear Wheel | 27.5” aluminum, tubeless ready, 32-spoke |
| Performance | |
| Climbing Activity | Climb steep hills up to 20-30% grade |
| Recommended Riding Terrain | Off road, road |
| Cruising Speed (flat terrain) | 12-15 mph (20-24 kph) |
| Sprinting Speed (flat terrain) | 20+ mph (32+ kph) |
| Workout Resistance Selection | 10 different levels of resistance. 382% total resistance range. 16% difference between levels |
